AI Floor Plan Creator v2.0

The ultimate house layout generator for Indian construction. Set your dimensions on the left to automatically generate Vastu-compliant 2BHK, 3BHK, and 4BHK floor plans. Our AI Construction Hub instantly provides structural layouts, steel estimates, and 100% Vastu privacy optimizations.

Select specs to begin

Custom Layouts for 30' x 50' Plot

AI has generated two distinct architectural strategies for your 2BHK/3BHK/4BHK requirements.

Best for Open Space

Option A: Open Concept Modern

Synthesizing Option A...

Built-up

1,500 sq.ft

Steel Est.

6.3 MT

Cost Est.

₹4.2L

Key Advantage: Maximizes natural ventilation and provides a seamless flow between living and dining areas.

Best for Vastu

Option B: Vastu Focused Privacy

Aligning Vastu B...

Built-up

1,500 sq.ft

Steel Est.

6.3 MT

Cost Est.

₹4.2L

Key Advantage: 100% Vastu compliance with strict quadrant separation for privacy and spiritual harmony.

Sariya Bazar AI Floor Plan & Steel Estimation Technology

Sariya Bazar's AI Floor Plan Creator v2.0 is an advanced algorithmic architectural generator designed specifically for Indian residential and commercial construction. By synthesizing user plot dimensions, orientation, storey count (G, G+1, G+2), and Vastu Shastra preferences, our generative engine produces optimized floor plan options complete with structural steel quantity estimates.

1. Automated Steel & RCC Material Calculation (IS 456:2000)

Traditional estimation requires manual architectural blueprint drafting and tedious structural quantity takeoff. Our AI algorithm automates this by applying Indian Standard Code IS 456:2000 reinforcement ratios:

Slab Reinforcement: Calculated at 0.7% to 1.0% of gross concrete volume using 8mm and 10mm Fe 500D TMT rebar mesh.

Beam & Column Reinforcement: Calculated at 1.5% to 2.5% of concrete volume using 12mm, 16mm, and 20mm main structural bars with 8mm stirrup ties.

Footing & Foundation: Standardized mat foundation reinforcement configured according to soil bearing capacity parameters.

On average, a standard G+1 residential structure requires approximately 3.8 kg to 4.5 kg of TMT steel per square foot of built-up area. Our AI instantly translates your plot dimensions into exact metric tonnage, allowing you to request wholesale quotes directly from local rolling mills.

2. Vastu Shastra Quadrant Alignment Engine

Vastu compliance is a crucial requirement for over 85% of Indian homebuilders. Option B in our generator strictly enforces ancient architectural spatial layout rules:

Master Bedroom: Positioned strictly in the South-West (Nairrutya) quadrant for stability and leadership.

Kitchen: Positioned in the South-East (Agneya) fire zone with cooking facing East.

Pooja Room & Entrance: Placed in the North-East (Eesanya) quadrant to maximize morning solar radiation and positive airflow.

Staircase & Overhead Tank: Placed in the South or West zones to add structural dead-weight where required.

3. Export & Direct Mandi Quote Integration

Once your preferred layout (Option A or Option B) is selected, you can export a full PDF blueprint or pass the calculated steel tonnage directly into our Steel Weight Calculator and B2B quote routing system to get live ex-mill prices from Raipur, Mandi Gobindgarh, and Mumbai stockists.
